High Consistency Refiner for Pulp

High Consistency Refining Machine

High Consistency Refiner for Pulp is suitable for different kinds of pulp. The set of equipment include control system, lubrication system, hydraulic execution system, detection and protection system. The purification effect is stable.

The high-concentration refiner, referred to as the high-concentration refiner, is a mandatory feed for high-concentration pulp mills. Suitable for chemical pulp, semi-chemical mechanical pulp, polished high-yield pulp and fiberboard materials. The application range of the slurry is wide, the two kinds of bacteria are complex, the slurry materials are very different, the remaining debris remaining after wood processing, shavings, sawdust, pulp residue and cold-impregnated amaranth chips, straw, and the rotation speed is higher. Appropriate use of high quality fiber. Its advantages are: high consistency refining, reducing fiber cutting, wire brush effect, high grinding efficiency, low unit energy consumption.

NO Item Model Model Model
1 Model TZGNM915 TZGNM1000 TZGNM1250
2 Diameter 915mm 1000mm 1250mm
3 Speed 1480rpm 1480rpm 1480rpm
4 Voltage 10KV 10KV 10KV
5 Power 400-710KW 560-1250KW 1120-1600KW
6 Capacity t/d t/d t/d
Mechanical pulp 50-70t/d 80-100t/d 110-140t/d
Straw pulp 80-100t/d 90-120/d 130-170t/d
Bamboo pulp 200-300t/d 300-350t/d 350-400t/d
7 Consistency 15-35% 15-35% 15-35%
8 Feeding motor 7.5KW-11KW 11KW-15KW 15KW-18.5KW
